Here are the direct Isp Pinout for Oppo F7 CPH1819 Remove Pattern Lock Bypass FRP Lock is now available. You can easily get the ISP Pinout connection of the Oppo F7 by following the full guide below along with images. By using the ISP Pinout, you can easily bypass FRP lock or reset user data on your device via UFi Box. Check out the guide below.
The Oppo F7 can be used to overcome some software problems on Oppo F7 CPH1819 phone, to direct it you can use a flasher box that has direct isp feature support and usually the flasher box can also be used for repairing emmc like Easy Jtag, Ufi, etc.
Remove Pattern Lock, Screen Lock, Finger Lock in Oppo F7 CPH1819 with UFI Box you can easily solve with this method if you are fresher technician or experienced technician in android software related if the error occurs of USB not recognized then your USB is not working.if a battery is not charged, your USB socket will not properly work and you will fail in this method. if any issues please write your questions in the comment box I will try my best to help you.
Oppo F7 Overview
OPPO F7 smartphone runs on Android v8.1 (Oreo) operating system. The phone is powered by Octa core (2 GHz, Quad core, Cortex A73 + 2 GHz, Quad core, Cortex A53) processor. It runs on the MediaTek Helio P60 Chipset. It has 4 GB RAM and 64 GB internal storage.
What is ISP Or eMMC Pinout?
ISP orIn-system programming also known as in-circuit serial programming for hardware that has a cross-reference of pins or contacts. By shorting the pins together, you can power or signal the logic board (motherboard) of an electronic device such as a mobile. The eMMC solution consists of at least three components – the MMC (multimedia card) interface, the flash memory, and the flash memory controller – and is offered in an industry-standard BGA package.
Usage of ISP Pinout :
Read/Write EMMC via ISP.
Read/Write EMMC via direct connect (EMMC installed in socket).
One-click boot repair via direct emmc connection.
Read MMC info (Many usefull info there such as read/write counter, error counter, etc)
Factory EMMC formatting.
Low EMMC formatting.
Master/Slave partition activation
EMMC smart repartition.
EMMC partition cloning.
Oppo F7 CPH1819 ISP Pinout Image
How To Remove Oppo F7 Pattern FRP Using UFI Dongle:
- Remove the back panel of the device and connect the wire to the ISP Pinout.
- Next, connect the correct ISP Pinout to the UFi Box
- Check “Direct eMMC (ISP)”
- Then Click on “Identify eMMc.
- Connect your Oppo F7 to the PC via a USB cable.
- Head over to the PC and open Device Manager.
- If your device is located there, run the UFi Box.
- Go to USERAREAPART
- Now Click on Special Task ► [Oppo] MasterClear ► Wipe Data Only
- Now Click on Special Task ► Clear FRP Lock
