Samsung Galaxy A22 5G A226B Test Point | ISP PinOUT Image


Samsung Galaxy A22 5G A226B Test Point ISP PinOUT to Remove Pattern Lock, FRP, And Flashing, Dead Boot Repair

Each and every phone comes with different developer options like Recovery mode, Fastboot mode/bootloader mode, and EDL mode. All these modes use to perform different testing processes. Some of them only can be used for advanced android users or developers or mobile repairing and some of them can be used by normal users.

In this guide, we will show you how to boot Samsung Galaxy A22 5G A226B into MTK Download mode to flash stock ROM. If you are thinking to install software on bootloader-locked Samsung Galaxy A03s mobile then you need to boot the device into emergency download mode. After that, you can flash it.

How To Remove Samsung Galaxy A22 5G A226B Pattern Lock and  FRP:

You can use EFT dongle, UMT dongle, octopus FRP tool, MRT key tool for remove FRP and pattern lock from Samsung Galaxy A22 5G A226B or you can try other tools use the above test point to boot your phone in an emergency download mode remove Battery short test point to the ground and insert USB cable.

What is Samsung Galaxy A22 ISP Pinout?

ISP means “In-System Programming”.In-System Programming (ISP) allows communication to take place with a target chip without the need to remove it. The main advantage of this method is the possibility to communicate with a target chip eMMC or eMCP bypassing the CPU. It brings higher speed for data extraction compared with JTAG but it requires great soldering skills. ISP applied to forensics, is the practice of connecting to an eMMC or eMCP flash memory chip for the purpose of downloading a device’s complete memory contents.

Read More:-  Huawei Mate 10 Lite Test Point For Remove Pattern, FRP And Flashing

Samsung Galaxy A22 5G A226B Test Point – ISP PinOUT Image

How To Find Samsung Galaxy A22 Test Point.

  • Install “Samsung Galaxy A22 5G A226B MTK USB Drivers” on a windows pc.
  • Remove back panel of the device carefully. Make sure you are not going to damage any hardware component.
  • Now check the below screenshot and find the Samsung Galaxy A22 5G A226B Test points.

Samsung Galaxy A22 5G A226B Test Point   ISP PinOUT Image

  • Remove the battery and Short bot points using any copper wire and attach a USB cable at the same time.
  • Now you are free to flash stock ROM on Samsung Galaxy A22 5G A226B mobile using any tool.

Uses Of Samsung Samsung Galaxy A22 5G A226B Test Point

  • Install stock ROM on.
  • Flash without unlocking the bootloader. Bootloader unlocking permission is not required.
  • Recovery dead by flashing firmware.
  • Install stock ROM easily, if the device is not able to boot into fastboot mode or the device stuck on Samsung Logo.

What is Screen Lock for Samsung Galaxy A22 5G:

Screen Lock is a privacy lock for android, many ways to enable screen locks on your device if screen lock enabled then the user need to enter the right password, Pattern, Pin lock to access devices again, screen lock means you can lock your device by pattern lock, password lock, pin lock, nowadays face locks and fingerprint lock also include in the screen locks menu,

Why do we need to Remove the Screen Lock?

If you forget the screen locks from your device and went to remove the pattern lock from your device then I am here to share with you the right method to Remove Pattern lock, Password lock, and Pin locks. or If your device shows too many attempts to unlock the pattern if you want to unlock then follow the below process very carefully.

Read More:-  Huawei Y5 (2019) ISP Pinout to ByPass FRP and Pattern Lock
